STV Valve Technology Group Co.,Ltd
Country: China
SCPH2 Swing Check Valve, 10K, 125A,Flange End
 |
|
Design standard: JIS B222214
Body material: SCS13.
Nominal diameter: 5" (DN125).
Pressure: JIS20K (PN25).
End connection: FF.
Face to face: JIS B2002.
Working temperature: -20℃~+300℃.
Test and inspection: API 598.
Product Range
Body Material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2"~24" (DN15~DN600).
End connection: BW, Flanged.
Pressure range: 10K~30K (PN16~PN64).
Operation: Handwheel, Gearbox, Electric, Pneumatic.
Working temperature: -20℃~+460℃.
Product Keywords of SCPH2 Swing Check Valve, 10K, 125A,Flange End
